Frequency range - 20-20.000 Hz
Frequency response - 20-18.000 Hz + 2 / - 3 dB
Tracking ability at 315Hz at recommended tracking force *) - 60 µm
Compliance, dynamic, lateral - 20 µm/mN
Stylus type - Elliptical
Stylus tip radius - r/R 8/18 µm
Equivalent stylus tip mass - 0,5 mg
*) Typical value
Frequency response - 20-18.000 Hz + 2 / - 3 dB
Tracking ability at 315Hz at recommended tracking force *) - 60 µm
Compliance, dynamic, lateral - 20 µm/mN
Stylus type - Elliptical
Stylus tip radius - r/R 8/18 µm
Equivalent stylus tip mass - 0,5 mg
*) Typical value
Tracking force range - 1,5-2,0 g (15-20 mN)
Tracking force, recommended - 1,75 g (17,5 mN)
Tracking angle - 20°
Stylus colour - Black
Tracking force, recommended - 1,75 g (17,5 mN)
Tracking angle - 20°
Stylus colour - Black
