TEKNİK ÖZELLİKLER
| Technical data | |
| Output voltage at 1 kHz 5 cm/sec | 0,45 mV |
| Channel balance | < 1,5 dB |
| Channel separation at 1 kHz | > 23 dB |
| Channel separation at 15 kHz | > 15 dB |
| Frequency range at -3 dB | 20 Hz - 50 kHz |
| Frequency response 20 Hz - 20 kHz | +3/-1 |
| Tracking ability at 315 Hz at recommended tracking force *) | 80 μm |
| Compliance, dynamic, lateral | 12 μm/mN |
| Stylus type | Nude Fine Line on Alu cantilever |
| Stylus tip radius | r/R 8/40 |
| Tracking force range | 2,2-2,7 g (22-27 mN) |
| Tracking force recommended | 2,5 g (25 mN) |
| Tracking angle | 20º |
| Internal impedance, DC resistance | 5 Ohm |
| Recommended load impedance | 50-500 Ohm |
| Cartridge body material | Stainless steel Aluminium |
| Cartridge colour | Red/Black |
| Cartridge weight | 10,7 g |
